FR - LEAD FREE

PVC Insulated Industrial Cables (Multi Strand) 1100 Valts

High Current Carrying Capacity
Energy Saving
Higher Flexibility
High Fire Retardancy
Glossy & Smooth Surface Finish
Low Emission of Toxic Gases
Computerized Cable Design
Free from hazardous substances
PRODUCT FEATURE
  • High Insulation Resistance
  • High abrasion Resistance
  • ROHS Complaint
  • Smooth & glossy surface with           Enhanced lubrication properties.
Osym Wires
DESIGN
  • Plain annealed bunched circular copper conductor
  • Insulation: Flexible PVC compound
APPROVALS
  • IS 8130 : 2013 BIS
CORE IDENTIFICATION
  • Red, Yellow, Blue, Black Green (Customised      Color can be provided)
CABLE CHARACTERISTICS

Normal Voltage (U0/U) : 600 / 1100 V
Max Operating Temperature : 70C
Temperature Range : -15C to + 70 C
Flame Resistant : ASTM D2863
Flammability : IEC 60332 – 1:2004
Minimum Bending Radius : 8D

APPLICABLE STANDARD
  • IS 694 : 2010
  • IEC 60332 – 1 : 2004
  • ASTM 2863 : ASTM D2803 – 17A
black
blue
green
red
white
yellow
